Product Name : J800
Code : J800
Introduction
Item No.: J800 This product is TPU polyether base. Main composition is polyurethane. This film exhibits great adhesion to many fabrics. High frequency welding, ultrasonic welding, and heat press are suggested for bonding. We accept made to order to all items.
Specification： Thickness: 0.03mm~2.0mm Width: 36"~54" Color: All colors available
Features： ★Hydrophilic ★Waterproof ★Hydrolysis resistance ★Excellent tear strength ★Low density ★Soft ★Can be sterilized ★Washable ★Good winding resistance when low temperature
Applications： ‧Gloves ‧Wind jacket，rain jacket ‧Swimming suit，hat
| Unit | Test Standard(ASTM) | J800 | FIELD5 | |
|---|---|---|---|---|
| Ester | ||||
| Ether | ● | |||
| Hardness | shores A | D-2240 | 74 | |
| Density | g/cm3 | D-792 | 1.08 | |
| Tensile Strength | Mpa | D-412 | 26.2 | |
| Tear Strength | KN/M | D-624 | 67.6 | |
| Elongation | ％ | D-412 | 660 | |
| Processing Temperature | ℃ | 135 | ||
| Hydrolysis Resistant | Grade | D-3137 | ◎ | |
| U.V. Stability | Grade | D-1148 | ■ | |
| Moisture Vapor Transmission(M.V.T) | g/㎡/day | E96BW | >3000 | |
| W.P.R. | mmH2O | JIS L1092 | >10000 | |
| Carrier | PE/PA |
NOTE: ◎Excellent ■Good ▲Fair ** The above is for reference only, our company reserve the right to amend.**
